NFT PVC Pipe Wall System

At a Glance

How This System Works

Nutrient Film Technique works by pumping a thin film of nutrient solution through slightly tilted channels. The solution flows from the high end of each channel to the low end, where it drains back into a reservoir below. Plants sit in net cups inserted into holes along the top of each channel, with their roots extending down into the flowing nutrient film.

The key word is "film" — the water should only be 1–3 mm deep as it flows through the channel. This thin layer keeps the upper portion of the roots exposed to air for oxygen while the lower roots absorb water and nutrients from the flowing solution.

Why wall-mounted PVC? Mounting the channels vertically on a wall saves valuable floor space. Three 4-foot PVC channels stacked vertically give you 12 plant sites in just 2 feet of wall space. The slight tilt of each channel (about 1 inch drop per 4 feet) provides gravity-fed flow from one end to the other.

Materials List

Our philosophy: Use what you already have. Hydroponics does not require store-bought equipment. People around the world grow food this way using recycled containers, scraps of fabric, and seeds saved from last season's harvest. The links below are for convenience if you prefer to purchase, but we encourage you to improvise with what is available to you.

This page contains affiliate links. If you purchase through them, we may earn a small commission at no extra cost to you. Learn more

Channels

PVC pipes or pre-made NFT channels hold the plants. Use what you have: You can build channels from 4-inch PVC fence posts (square profile), rain gutters, or 3-inch round PVC pipe. Cut 3-inch holes in the top every 8 inches for net cups. This DIY approach takes more work but costs almost nothing. If you want pre-made channels, NFT hydroponic channels (4-pack with lids and net cups) save time.

Reservoir

A dark storage tote sits on the floor below the channels. Use what you have: Any opaque plastic container works. An old storage bin, bucket, or cooler is fine as long as it blocks light and prevents algae. A 10-gallon dark storage tote is a good size if you need to buy one.

Net Cups

3-inch net cups fit the standard NFT channel holes. Use what you have: Cut the bottoms off small plastic cups and poke a few drainage holes. They do the same job. Or pick up a pack of 3-inch net cups (25-pack).

Pump & Plumbing

You will need a small submersible pump and tubing to circulate the nutrient solution:

• 1x submersible water pump (80–160 GPH, adjustable flow preferred)
• 10 ft of 1/2-inch vinyl tubing
• 3x T-splitters or a manifold to distribute flow to each channel
• 3x elbow fittings for drainage returns
• Teflon tape for threaded connections

Growing Supplies

Use what you have: A small piece of sponge or a cotton ball will hold a seed until it sprouts, and you can transplant seedlings you already have growing. For convenience, Rapid Rooter plugs (50-pack) make starting seeds easy.

Nutrients are the one thing you really need to buy. Plants growing in water need dissolved minerals, and there is no homemade substitute. The good news is a single kit lasts for months. We recommend the General Hydroponics Flora Series (3-part kit).

Monitoring & Timing

Use what you have: pH test strips from a pet store or pool supply aisle work well enough to get started. For more accurate readings, a digital pH and TDS meter kit takes the guesswork out.

You can manually switch the pump on and off, or look for a timer at a thrift store. A programmable outlet timer handles the schedule automatically.

Lighting

For indoor growing, mount a grow light to illuminate all three channels. Use what you have: A sunny window or basic 4000K LED shop lights from a hardware store do the job nicely. For dedicated grow lighting, consider full-spectrum 4 ft LED grow lights.

Mounting Hardware

• 6x heavy-duty L-brackets or shelf brackets (rated for 20+ lbs each)
• 12x wall anchors and screws (use toggle bolts for drywall)
• Level, drill, and measuring tape

Tools

• Drill with standard bit set
• Hole saw (3-inch) if making DIY channels from PVC pipe. You can also trace and cut holes with a box cutter or utility knife. If you need a hole saw, here is a 3-inch hole saw.

Build Instructions

Step 1: Plan the Wall Layout

Choose a wall near a power outlet. Map out three horizontal channels stacked vertically:

• Bottom channel: 12 inches above the floor (above the reservoir)
• Middle channel: 28 inches above the floor
• Top channel: 44 inches above the floor

Each channel will be 48 inches long and tilted slightly — the inlet end (where nutrient pumps in) should be 1 inch higher than the drain end. Mark bracket positions on the wall.

Step 2: Install the Wall Brackets

• Mount 2 L-brackets per channel (6 total) at the marked positions
• Use a level to ensure each pair of brackets has the correct 1-inch slope from inlet to drain
• Use toggle bolts or stud anchors — the channels will hold water and be heavy

Step 3: Prepare the Channels

If using pre-made NFT channels, they should come with net cup holes already cut. If building from PVC pipe:

• Mark 4 evenly spaced holes per channel (every 10 inches, starting 5 inches from each end)
• Cut 3-inch holes using a hole saw
• Sand all edges smooth
• Install end caps on both ends of each channel
• Drill a 1/2-inch inlet hole at the high end of each channel
• Drill a 1/2-inch drain hole at the low end of each channel (at the bottom of the channel, not the top)

Step 4: Set Up the Reservoir

• Place the 10-gallon reservoir tote on the floor directly below the drain ends of the channels
• Position the submersible pump inside the reservoir
• Fill with water — you will add nutrients in a later step

Step 5: Connect the Plumbing

Safety Warning: The submersible pump is an electrical device submerged in water. Always plug into a GFCI-protected outlet. Create a drip loop in all power cords near the outlet.

Supply side (pump to channels):

• Connect 1/2-inch tubing from the pump outlet
• Run it up the wall to the top channel
• Use T-splitters to branch the line to each channel's inlet hole
• Secure tubing to the wall with cable clips to keep things tidy

Drain side (channels back to reservoir):

• Attach short lengths of 1/2-inch tubing to each channel's drain hole
• Route all three drain lines back into the reservoir
• Ensure drain lines are lower than the channel drain holes so gravity flow is unobstructed

Step 6: Test the Flow

• Fill the reservoir with plain water
• Turn on the pump
• Check that water flows evenly through all three channels
• Verify the flow is a thin film (1–3 mm deep), not a flood — adjust the pump flow rate if needed
• Check all connections for leaks
• Run for 30 minutes and re-inspect

Tip: If the flow is too strong, use the pump's adjustable dial or add a ball valve on the supply line.

Step 7: Mix Nutrients

Once the plumbing is leak-free:

• Drain the plain water
• Refill with fresh water and mix nutrients:
  • Target EC: 0.8–1.4 mS/cm for leafy greens
  • Target pH: 5.5–6.5
• Run the pump and re-test pH after 1 hour (it may drift initially)

Step 8: Install Grow Lights

Mount your 4-ft LED grow light above the top channel, angled to illuminate all three tiers. If one light does not cover all channels evenly, use two lights — one above the top channel and one between the middle and bottom channels.

Set a timer for 16 hours on / 8 hours off.

Step 9: Plant Your Seedlings

• Start seeds in rapid rooter plugs 7–14 days before your system is ready
• Once seedlings have visible roots, place each plug in a net cup with a little hydroton for support
• Insert net cups into the channel holes
• Ensure the bottom of each net cup touches or nearly touches the flowing nutrient film

Step 10: Final Checks

• Verify pump is running and nutrient film is flowing in all channels
• Confirm all net cups are properly seated
• Check that lights are on the correct timer schedule
• Ensure no light is reaching the reservoir (cover with a dark lid)

Nutrient Guide

NFT-specific note: Because the nutrient film is thin and constantly recirculating, pH and EC can shift faster than in a large DWC reservoir. Check levels every 2–3 days.

Crop Suggestions

Note: NFT is best for lightweight crops. Avoid heavy fruiting plants like tomatoes — their root mass can block the thin nutrient film and cause flow problems.

Estimated Cost

Tips & Troubleshooting

General tips:

• Always have a backup plan for pump failure — without flow, NFT plants can wilt within hours
• Keep a spare pump on hand
• Stagger your planting dates so you always have plants at different growth stages
• The slight angle is critical — too flat and water pools, too steep and the film moves too fast

Maintenance Schedule

Daily

• Quick visual check: is the pump running? Is nutrient film flowing in all channels?
• Look for wilting or discoloration

Every 2–3 Days

• Check pH and EC — NFT systems can shift quickly
• Top off reservoir — add pH-adjusted water or nutrient solution as needed
• Inspect channels — ensure flow is not blocked by roots

Weekly

• Clean pump intake — remove any debris or root fragments
• Check for leaks — inspect tubing connections and channel joints
• Wipe down channels at the inlet and drain points

Every 2 Weeks

• Full reservoir change — dump, scrub, refill with fresh nutrient solution
• Trim overgrown roots if they are restricting flow

Monthly

• Deep clean channels — flush with plain water and a mild hydrogen peroxide solution
• Inspect mounting brackets for stability
• Clean or replace pump filter
• Check grow light height and adjust as plants grow

Frequently Asked Questions

How often should I run the pump in an NFT system?

NFT systems are designed to run continuously, not on a timer cycle like drip or ebb and flow setups. The nutrient film must flow at all times because the channels hold very little water on their own. If the pump stops, the thin film drains away within minutes and roots begin to dry out, which can cause permanent wilting damage in as little as two to four hours in warm conditions.

Can I grow tomatoes or other fruiting plants in a wall-mounted NFT system?

Wall-mounted NFT systems are best suited for lightweight leafy greens and herbs. Fruiting plants like tomatoes and peppers develop large, dense root systems that can block the thin nutrient film and cause flow problems in the channel. They also grow tall and heavy, putting excessive strain on wall-mounted brackets. If you want to grow fruiting crops hydroponically, a drip bucket system or deep water culture setup is a much better choice.

What happens if the power goes out and my NFT pump stops?

A power outage is the biggest risk for an NFT system because plants rely entirely on the pump for water and nutrients. In warm conditions, plants can begin wilting within two to four hours without flow. To protect against this, keep a battery-powered backup air pump or a small uninterruptible power supply on hand, and consider adding a larger reservoir so that any residual moisture in the channels lasts longer.

How do I prevent algae from growing inside my NFT channels?

Algae thrives wherever light meets moisture, so the key is blocking all light from entering the channels and reservoir. Use opaque PVC pipe or pre-made channels, cover any gaps around net cups with foam collars or neoprene discs, and keep the reservoir lid sealed tightly. If algae does appear, flush the channels with a dilute hydrogen peroxide solution during your next reservoir change and ensure every opening is light-proofed.
